AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.3.4 AIN.ISCALE
General Information
Type NV Parameter
Description
Sets the analog current scale fac-
tor.
Units A/V
Range 0.001 to 22.4 A/V
Default
Value
0.001 A/V
Data Type Float
Start Version M_01-01-01-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 4 No 32 bit No M_01-03-00-000
Description
AIN.ISCALE sets the analog current scale factor that scales the analog input (AIN.VALUE) for
DRV.OPMODE = 1 (analog torque mode).
The value entered is the motor current per 10 V of analog input. This value may be either higher
or lower than 100%, but the actual analog input will be limited by the application current limit
(IL.LIMITN and IL.LIMITP ).
Related Topics
129 Kollmorgen™ | March 30, 2012
