AKD BASIC User Guide | 6 AKD BASIC Parameters, Operators, Statements
6.23.21 MOTOR.VOLTMAX
General Information
Type NV Parameter
Description
Sets the motor maximum volt-
age.
Units Vrms
Range 110 to 900 Vrms
Default
Value
230 Vrms
Data Type Integer
See Also N/A
Start Version M_01-00-00-000
Fieldbus Index/Subindex Object Start Version
EtherCAT COE and CAN-
open
3452h/0 M_01-00-00-000
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 524 No 16 bit No M_01-03-00-000
Description
This parameter sets the maximum permissible motor voltage. For instance, if a motor that is
rated for a 400 V supply is connected to the drive, then the MOTOR.VOLTMAX setting is 400.
This value also sets regen resistor and over voltage thresholds in the drive to acceptable values
for the motor so that the motor windings are not damaged.
359 Kollmorgenâ„¢ | March 30, 2012
