CLI Commands
4.9 I
SCALANCE W1750D CLI
180 Function Manual, 03/2019, C79000-G8976-C452-04
Creates a DHCP profile with a unique name.
Defines the branch ID.
You can allocate BID per subnet. The AP
generates a subnet name from the DHCP IP
configuration, which the controller can use
as a subnet identifier. If static subnets are
configured in each branch, all of them are
assigned the with BID 0, which is mapped
directly to the configured static subnet.
— —
Defines the number of clients allowed per
DHCP branch.
The client count configured for a
branch determines the use of IP addresses
from the IP address range defined for a
DHCP scope. For example, if 20 IP ad-
dresses are available in an IP address range
configured for a DHCP scope and a client
count of 9 is configured, only a few IP ad-
dresses (in this example, 9) from this range
will be used and allocated to a branch. The
AP does not allow the administrators to
assign the remaining IP addresses to anoth-
er branch, although a lower value is config-
ured for the client count.
— —
<default_router>
Defines the IP address of the default router
for the Distributed, L2 , Local, Local, L2, and
— —
Enables the APs to intercept the broadcast
packets and relay DHCP requests directly to
corporate network.
The DHCP relay is enabled for the central-
ized DHCP scopes to reduce network traffic
caused by the broadcasting of DHCP re-
quests to the corporate network. With a
centralized DHCP scope, the clients in the
branch are in the same subnet as clients in
the corporate network. Normally the DHCP
request goes through the VPN tunnel and is
broadcast into the corporate network. This
feature allows it to succeed without requiring
to broadcast and thus reduces the network
— —
server>
Defines the IP address of the corporate
DHCP server for DHCP request relay.
— —
Enables dynamic dns updates for this pool.
