CLI Commands
4.16 S
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04
355
4.16.65 show ap debug power-table
Description
This command displays the following information for a specific radio:
● Power limit table based on regulatory powers, user configured power, and override
powers.
● Board limit table.
● A combination of all the above fields to calculate the actual transmit power of the packets.
Syntax
show ap debug power-table {<radio>
Denotes the polarization value for the radio channel
Example
The following example shows the output of the show ap debug power-table command.
(scalance)# show ap debug power-table 1
Combined CONDUCTED Limits(dBm) 11
#Antenna 1:
#NSS 1: CCK:
CDD 18.0 18.0 18.0 18.0
CDD+CRPOL 18.0 18.0 18.0 18.0
TXBF * * * * TXBF+CRPOL * * * * OFDM:
TXBF * * * * * * * * TXBF+CRPOL * * * * * * * *
Mode HT/VHT 20:
