CLI Commands
4.16 S
SCALANCE W1750D CLI
338 Function Manual, 03/2019, C79000-G8976-C452-04
D - Delayed BA; G - Greenfield; R - Dynamic SM PS
Q - Static SM PS; N - A-MPDU disabled;
B - TX STBC b - RX STBC; M - Max A-MSDU; I - HT40 Intolerant
The output of this command includes the following information:
Parameter
Description
MAC
Indicates the MAC address of the AP.
ESSID
Indicates the Extended Service Set identifier (ESSID) used by the client. An
ESSID is a user-defined name for a wireless network.
BSSID
Filters the AP Config table by BSSID. The Basic Service Set Identifier
(BSSID) is usually the AP’s MAC address.
Assoc_State
Shows whether or not the client is currently authorized and/or associated
with the AP.
HT_State
Shows the client’s high-throughput (802.11n) transmission type:
none: AP is a legacy access point that does not support the 802.11n stand-
ard.
• 20Mhz: A high-throughput APs using a single 20 Mhz channel.
• 40Mhz: A high-throughput APs using two 20 Mhz channels.
AID
Indicates the 802.11 association ID. A client receives a unique 802.11 asso-
ciation ID when it associates to an AP.
UAPSD
Shows the following values for Unscheduled Automatic Power Save Delivery
(UAPSD) in comma-separated format: VO, VI, BK, BE, Max SP, Q Len.
• VO: If 1, UAPSD is enabled for the VoIP access category. If UAPSD is
disabled for this access category, this value is 0.
• VI: If 1, UAPSD is enabled for the Video access category. If UAPSD is
disabled for this access category, this value is 0.
• BK: If 1, UAPSD is enabled for the Background access category. If
UAPSD is disabled for this access category, this value is 0.
• BE: If 1, UAPSD is enabled for the Best Effort access category. If
UAPSD is disabled for this access category, this value is 0.
• Max SP: The maximum service period is the number of frame sent per
trigger packet. This value is value can be 0, 2, 4 or 8.
• Q Len: The number of frames currently queued for the client, from 0 to
16 frames.
Tx_Pkts
Shows the number of packets transmitted by the client.
Rx_Pkts
Shows the number of packets received by the client.
PS_Qlen
Shows power save queue length, in bytes.
Tx_Pkts
Shows the packet rate from the AP to client.
Rx_Pkts
Show the packet rate from the client to AP.
Tx_Retries
Shows the number of packets that the client had to resend due to an initial
transmission failure.
