CLI Commands
4.16 S
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04
349
(scalance)# show ap debug lldp neighbor
-------------------------
Capability codes: (R)Router, (B)Bridge, (A)Access Point, (P)Phone, (O)Other LLDP
Neighbor Information
Interface Neighbor ID Capabilities Remote Interface Expiry-Time (Secs)
--------- ----------- ------------ ---------------- ------------------
eth0 00:0b:86:6b:57:80 B:R GE0/0/22 93
The output of this command includes the following information:
Parameter
Description
Interface
Indicates the interface on the AP sending or receiving LLDP PDUs.
Neighbor ID
Indicates the LLDP neighbor number.
Capabilities
This data column can list any of the following data codes to indicate LLDP
neighbor capabilities.
• R: Routern
• B: Bridgen
• A: Access Point
• P: Phone
• O: Other
Remote Inter-
face
Indicates the interface name on a peer device to which the AP port is connected.
Expiry-Time
(Secs)
Indicates the maximum time limit for sending and receiving LLDP PDUs.
The following example shows the output of show ap debug lldp state command.
(scalance)# show ap debug lldp state LLDP Interface Information
--------------------------
Interface LLDP TX LLDP RX LLDP-MED TX interval Hold Timer
--------- ------- ------- -------- ----------- ----------
eth0 Enabled Enabled Disabled 30 120
eth1 Enabled Enabled Disabled 30 120
Parameter
Description
Interface
Indicates the LLDP interface name.
LLDP TX
Shows if LLDP PDU transmission is enabled or disabled.
LLDP RX
Shows if the AP has enabled or disabled processing of received LLDP PDUs.
LLDP-MED
Shows if LLDP MED protocol is enabled or disabled.
TX interval
Indicates the LLDP transmit interval in seconds.
Hold Timer
Indicates the LLDP transmit hold multiplier.
