CLI Commands
4.16 S
SCALANCE W1750D CLI
376 Function Manual, 03/2019, C79000-G8976-C452-04
b8e356bcb60d4ce984d9a7077a439
36
HLK
50
-
0
0
0
HT-20MHzsgi-3ss
78042e34005c8b372de0472df072
7ef
Total count:
3, Children: 0
Relation: P = Parent; C = Child; N =
Neighbor; B = Blacklisted-neighbor
Flags: R = Recovery-mode; S = Sub-threshold link; D = Reselection
backoff; F = Auth-failure; H= High Throughput; L = Legacy allowed
K = Connected; U = Upgrading; G = Descendant-upgrading; Z
= Config pending; Y = Assoc- resp/Auth pending
a = SAE Accepted; b = SAE Blacklisted-neighbour; e = SAE
Enabled; u = portal-unreachable; o = opensystem
The output of this command includes the following information:
Parameter
Description
MAC
MAC address of the mesh node.
Portal
By default, this column displays the BSSID of the mesh point. If you include
the optional names parameter, this column will display AP names, if availa-
ble. The AP names will include [p] (parent), or [c] (child) suffixes to indicate
the role of the mesh BSSID.
Channel
Number of a radio channel used by the AP.
Age
Number of seconds elapsed since the AP heard from the neighbor.
Hops
Indicates the number of hops it takes traffic from the mesh node to get to
the mesh portal. The mesh portal advertises a hop count of 0, while all
other mesh nodes advertise a cumulative count based on the parent mesh
node.
Cost
A relative measure of the quality of the path from the AP to the Virtual Con-
troller. A lower number indicates a better quality path, where a higher num-
ber indicates a less favorable path (e.g, a path which may be longer or
more congested than a path with a lower value.) For a mesh point, the path
cost is the sum of the (parent path cost) + (the parent node cost) + (the link
cost).
Relation
Shows the relationship between the specified AP and the AP on the neigh-
bor list and the amount of time that relationship has existed.
• C = Child
• N = Neighbor
• B = Blacklisted-neighbor
Flags
This parameter shows additional information about the mesh neighbor. The
key describing each flag is displayed at the bottom of the neighbor list.
RSSI
The RSSI value displayed in the output of this command represents signal
strength as a signal to noise ratio. For example, a value of 30 would indi-
cate that the power of the received signal is 30 dBm above the signal noise
threshold.
Rate Tx/Rx
The rate, in Mbps, that a neighbor transmits data to or receives data from
the mesh-node specified by the command.
A-Req
Number of association requests from clients.
A-Resp
Number of association responses from the mesh node.
A-Fail
Number of association failures.
Cluster ID
Name of the Mesh cluster that includes the specified AP or BSSID.
