CLI Commands
4.16 S
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04
479
VLAN Type Subnet Mask Gateway Mode Rolemap
---- ---- ------ ---- ------- ---- -------
532 l2 192.168.132.0 255.255.255.0 0.0.0.0 remote,full-tunnel VLAN532
539 nat 192.168.1.0 255.255.255.0 192.168.1.1 local,split-tunnel VLAN532
538 l3 192.168.2.0 255.255.255.0 192.168.2.1 local,split-tunnel VLAN532
534 l2 0.0.0.0 255.255.255.255 0.0.0.0 remote,full-tunnel VLAN532
The output of this command displays the following information:
Displays the VLAN details.
Displays the type of DHCP assignment mode.
Displays the subnet details.
Displays the subnet mask details.
Displays the DNS server IP address.
Displays the gateway IP address.
Displays details of the tunnel mode.
Displays the role assigned to the clients.
The following example shows the output of the show dhcp opt82 xml-config command.
This is in a scenario where the XML file is not uploaded in flash and the DHCP option 82
parameters are not configured.
DHCP Option82 XML
----------------------------
XML File Downloaded in Flash : No XML based DHCP Option82 Configured : No
The following example shows the output of the
show dhcp opt82 xml-config command.
This is in a scenario where the XML file is successfully uploaded in flash and the DHCP
option 82 parameters are configured.
DHCP Option82 XML
----------------------------
XML File Downloaded in Flash : /tmp/mydhcpoption82.xmlXML File Load Command
:http://10.20.52.131/dhcp.xml
XML File Load Status : Success
XML based DHCP Option82 Configured : Yes DHCP Option82 Circuit_ID
-----------------------------------
->:Circuit_ID is added first in DHCP Opt82
->:SubOption APMAC to be added in ASCII format separated with <-> in lower-case at
position 1 in Circuit_ID of DHCP option82
DHCP Option82 Remote_ID
--------------------------------------
