time spoof arp rcvd: 0
last spoof mac: 00:00:00:00:00:00
The output of this command includes the following information:
Parameter
Description
State
Indicates if the AP is provisioned as master
master_beacon
Displays the number of beacons transmitted and received by the master
AP.
hierarchy_beacon
Displays the number of hierarchy beacons transmitted and received.
hierarchy_ack
Displays the number of hierarchy messages transmitted and received.
beacon_req
Displays the number of beacons required.
beacon_resp
Displays a response from the master AP to the beacon request of the
slave AP.
election wait
Displays the shortest waiting time of an AP between one Virtual Control-
ler going down and the new Virtual Controller becoming active.
timer slow
Indicates that the AP has waited longer than expected, and that the
timer slow is caused by a CPU overload.
master high cpu
Indicates the CPU usage of the master AP. The allowed limit is 85.
ap cpu usage
Indicates the CPU usage of the existing AP.
Slave->Pot-Master
Displays a count of transitions from slave to pot-master state.
Pot-master->Master
Displays a count of transitions from pot master to master state.
Pot-master->Slave
Displays a count of transitions from pot master to slave state.
last spoof arp rcvd
Displays the last detected ARP spoof attack.
last spoof mac
Displays the MAC address of the last spoof detected. last beacon re-
ceived ticks
max beacon miss ticks
Displays the maximum time between the current beacon and last bea-
con
hierarchy mode
Indicates that the AP is in hierarchy mode.
last hierarchy beacon
received ticks
Displays the time between the current hierarchy beacon and last hierar-
chy beacon.
provisioned master
denied
Indicates that the preferred AP has been denied as a
master.
Command Information
AP Platform
Command Mode
All platforms
Privileged EXEC mode
