CLI Commands
4.16 S
SCALANCE W1750D CLI
556 Function Manual, 03/2019, C79000-G8976-C452-04
Parameter
Description
Port
Displays the port number on the controller.
Type
Displays the port type.
Admin-State
Displays if the port is enabled or disabled.
Oper-State
Displays if the port is currently up and running.
STP-State
Displays if the spanning tree of this port is on or
off.
Dot3az
Displays if the Dot3az of this port is enabled or
disabled.
Loop-Protect
Shows the status of the loop protection feature.
Storm-Control
Shows the status of the storm control feature.
Loop-Detection-TX
Shows the number of loop packets transmitted on
the interface
Loop-Detection-RX
Shows the number of loop packets received on
the interface.
The following example shows the output of the show port status details command:
Swarm Port Stats
----------------
Mac Address
AP
IF Index Frames [in] Frames [out]
-----------
--
-------- ------------ ------------
20:4c:03:0e:c6:cf
20:4c:03:0e:c6:cf
0
10732
88696
20:4c:03:0e:c6:d0
20:4c:03:0e:c6:cf
1
310513
213194
20:4c:03:0e:c6:d1
20:4c:03:0e:c6:cf
2
271365
1682
Bytes [in]
Bytes [out]
Speed
Duplex
Link
------------
------------
-----
------
----
1413854
3584848
100
full
up
14283598
14585336
100
full
up
12482790
120570
0
full
down
The output of this command provides the following information:
Parameter
Description
Mac Address
Shows the MAC address of the AP.
AP
Shows the name of the AP.
IF Index
Shows the index of the AP interface.
Frames [in]
Shows the number of packets received on the interface.
Frames [out]
Shows the number of packets transmitted on the interface.
Bytes [in]
Shows the number of bytes received on the interface.
Bytes [out]
Shows the number of bytes transmitted on the interface.
Speed
Shows the speed of the Ethernet interface.
Duplex
Shows the full or half duplex value of the Ethernet interface.
Link
Shows the Up or Down state of the Ethernet interface.
