YASKAWA NX100 User Manual

6 Convenient Functions
6.3 Parallel Shift Job Conversion Function
6-31
149235-1CD
RE-CSO-A031
Variables used in an individual shift
Example 1) When selecting P010 for a coordinated job with R1 + R2:
Use P010 for R1.
Use P011 for R2.
Example 2) When selecting EX005 for multiple jobs with four stations:
Use EX005 for S1.
Use EX006 for S2.
Use EX007 for S3.
Use EX008 for S4.
Be sure to use the variables of which numbers are consecutive after the selected number.
The variables of which numbers are not consecutive are unable to be selected.
NOTE
P010
JOB R2
P011
JOB R1
EX005
EX006
EX007
EX008
JOB S1
JOB S2 JOB S3
JOB S4
228 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
