YASKAWA NX100 User Manual

9 Arc Welding Application
9.4 Registering Arc Welding Instructions
9-17
149235-1CD
RE-CSO-A031
With an Arc Start Condition File
Operation Explanation
1 Select the ARCON instruction
in the instruction area.
The ARCON instruction appears in the input buffer line.
2 Press [SELECT]. The DETAIL EDIT window appears.
3 Select “UNUSED.” The selection dialog box appears.
4 Select “ASF#( ).” When the welding conditions have been set in the ARCON
instruction additional items, the DETAIL EDIT window appears.
JOB
EDIT
DISPLAY
UTILITY
Main Menu ShortCut
! Turn on servo power
JOB CONTENT
JOB NAME: WORK A
0000 NOP
0001 MOVJ VJ=80.00
0002 MOVL V=800
0003 END
ARCON
TOOL: 00
CONTROL GROUP: R1
STEP NO: 0003
DETAIL EDIT
ARCON
ARCON
SET METHOD
: UNUSED
DATA
EDIT
DISPLAY
UTILITY
Main Menu ShortCut
! Turn on servo power
DETAIL EDIT
ARCON
SET METHOD
:
ASF#()
AC=
UNUSED
DATA
EDIT
DISPLAY
UTILITY
Main Menu ShortCut
! Turn on servo power
DETAIL EDIT
ARCON
ARCON AC=180 AVP=100 V=80 RETRY REPLAY
: AC= 180
: AVP= 100
: T= 0.30
: V= 80
: RETRY
: REPLAY
WELDING CURR
WELDING VOLT
TIMER
SPEED
RETRY
MODE
360 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
