YASKAWA NX100 User Manual

9 Arc Welding Application
9.4 Registering Arc Welding Instructions
9-42
149235-1CD
RE-CSO-A031
8 Press [ENTER]. The set contents are registered in the job.
Press [CANCEL] to return to the JOB CONTENT window when
the set contents are not to be registered.
• The ARCCTS or ARCCTE instruction is valid for only one step.
• If the move section specified by the move instruction is shorter than the distance
specified by additional item (DIS=XXX), the change is performed equally in the entire
section of the move instruction.
• If the ARCCTS or ARCCTE instruction specifies the distance as zero (DIS=0.0), the
change is performed equally in the entire section of the move instruction.
• A pair of ARCCTS and ARCCTE instructions can be used on one move instruction. In
that case, the ARCCTS instruction is executed first, and the ARCCTE instruction is
executed in the remaining part of the move section. If the remaining part of the move
section is 0mm, the ARCCTE instruction is not executed.
Operation Explanation
ARCCTE AC=134 AVP=100
0000 NOP
0001 MOVJ VJ=80.00
0002 MOVL V=800
0003 ARCON
0004 MOVL V=50
0005 ARCCTE AC=134 AVP=100
0006 END
JOB CONTENT
JOB NAME: WORK A
TOOL: 00
CONTROL GROUP: R1
STEP NO: 0003
ARCCTE AC=200 AVP=100
0000 NOP
0001 MOVJ VJ=80.00
0002 MOVL V=800
0003 ARCON
0004 MOVL V=50
0005 END
JOB CONTENT
JOB NAME: WORK A
TOOL: 00
CONTROL GROUP: R1
STEP NO: 0003
NOTE
385 of 493
