1 Introduction

1.4 About the Security Mode

1-20

149235-1CD

RE-CSO-A031

*1 Displayed in the teach mode only.

*2 Displayed in the play mode only.

Menu & Security Mode

Main Menu Sub Menu

Security Mode

DISPLAY EDIT

JOB JOB Operation Edit

SELECT JOB Operation Operation

CREATE NEW JOB

Edit Edit

MASTER JOB Operation Edit

JOB CAPACITY Operation -

RES. START(JOB)

Edit Edit

RES. STATUS

Operation -

CYCLE Operation Operation

VARIABLE BYTE Operation Edit

INTEGER Operation Edit

DOUBLE Operation Edit

REAL Operation Edit

STRING Operation Edit

POSITION(ROBOT) Operation Edit

POSITION(BASE) Operation Edit

POSITION(ST) Operation Edit

LOCAL VARIABLE Operation -

IN/OUT EXTERNAL INPUT Operation -

EXTERNAL OUTPUT Operation -

UNIVERSAL INPUT Operation -

UNIVERSAL OUTPUT Operation Edit

SPECIFIC INPUT Operation -

SPECIFIC OUTPUT Operation -

RIN Operation -

CPRIN Operation -

AUXILIARY RELAY Operation -

CONTROL INPUT Operation -

PSEUDO INPUT SIG Operation Management

NETWORK INPUT Operation -

NETWORK OUTPUT Operation -

ANALOG OUTPUT Operation -

SV POWER STATUS Operation -

LADDER PROGRAM Management Management

I/O ALARM Management Management

I/O MESSAGE Management Management

44 of 493

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
