1 Introduction
1.4 About the Security Mode
1-21
149235-1CD
RE-CSO-A031
Menu & Security Mode
Main Menu Sub Menu
Security Mode
DISPLAY EDIT
ROBOT CURRENT POSITION Operation -
COMMAND POSITION Operation -
SERVO MONITOR Management -
WORK HOME POS Operation Edit
SECOND HOME POS Operation Edit
DROP AMOUNT Management Management
POWER ON/OFF POS Operation -
TOOL Edit Edit
INTERFERENCE Management Management
SHOCK SENS LEVEL Operation Management
USER COORDINATE Edit Edit
HOME POSITION Management Management
MANIPULATOR TYPE Management -
ROBOT CALIB Edit Edit
ANALOG MONITOR Management Management
OVERRUN&S-SENSOR
*1
Edit Edit
LIMIT RELEASE
*1
Edit Management
ARM CONTROL
*1
Management Management
SHIFT VALUE Operation -
SYSTEM INFO VERSION Operation -
MONITORING TIME Operation Management
ALARM HISTORY Operation Management
I/O MSG HISTORY Operation Management
SECURITY Operation Operation
FD/CF LOAD Edit -
SAVE Operation -
VERIFY Operation -
DELETE Operation -
DEVICE Operation Operation
FOLDER Edit Edit
FORMAT
*5
Operation Operation
*1 Displayed in the teach mode only.
*5 For FC1/FC2 Floppy disk
