YASKAWA NX100 User Manual

1 Introduction
1.4 About the Security Mode
1-22
149235-1CD
RE-CSO-A031
PARAMETER S1CxG Management Management
S2C Management Management
S3C Management Management
S4C Management Management
A1P Management Management
A2P Management Management
A3P Management Management
A4P Management Management
RS Management Management
S1E Management Management
S2E Management Management
S3E Management Management
S4E Management Management
SETUP TEACHING COND Edit Edit
OPERATE COND Management Management
DATE/TIME Management Management
GRP COMBINATION Management Management
RESERVE JOB NAME Edit Edit
USER ID Edit Edit
SET SPEED Management Management
KEY ALLOCATION
*1
Management Management
RES. START(CNCT) Management Management
AUTO BACKUP SET
*3
Management Management
WRONG DATA LOG
*4
Operation Management
ARC WELDING ARC START COND. Operation Edit
ARC END COND. Operation Edit
ARC AUX COND. Operation Edit
POWER SOURCE COND. Operation Edit
ARC WELD DIAG. Operation Edit
WEAVING Operation Edit
ARC MONITOR Operation -
HANDLING HANDLING DIAG. Operation Edit
SPOT WELDING WELD DIAGNOSIS Operation Edit
I/O ALLOCATION Management Management
GUN CONDITION Management Management
SPOT POWER SOURCE COND. Management Management
Menu & Security Mode
Main Menu Sub Menu
Security Mode
DISPLAY EDIT
*1 Displayed in the teach mode only.
*3 From NS3.20
*4 From NS3.21
46 of 493

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
