9 Arc Welding Application
9.13 Power Source Condition File Initial Value
9-100
149235-1CD
RE-CSO-A031
POWER SOURCE NO.: 7
POWER SOURCE NAME:
MOTOWELD-S350-AJ2/3
COMMENT: STC NO-CONTROL
POWER SUPPLY: independent
SHIELDING GAS: CO2
WIRE DIA.: 1.2mm
WIRE STICKOUT: 15mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 0.6sec
POWER SOURCE NO.: 8
POWER SOURCE NAME:
MOTOWELD-S350-AJ2/3
COMMENT: STC NO-CONTROL
POWER SUPPLY: independent
SHIELDING GAS: MAG
WIRE DIA.: 1.2mm
WIRE STICKOUT: 15mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 0.6sec
CURRENT VOLTAGE CURRENT VOLTAGE
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
RANGE: positive
ADJ.: 1.00
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(V)
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(V)
1.00 100 2.00 18.0 1.00 95 1.20 16.0
2.00 145 3.10 20.0 2.00 150 2.00 18.0
3.50 185 4.90 23.0 3.50 200 3.60 21.0
5.00 230 7.00 26.5 5.00 240 6.30 26.0
7.00 270 10.70 33.0 7.00 280 10.00 32.5
10.00 350 0.00 0.0 10.00 350 0.00 0.0
0.00 0 0.00 0.0 0.00 0 0.00 0.0
0.00 0 0.00 0.0 0.00 0 0.00 0.0
