YASKAWA NX100 User Manual

9 Arc Welding Application
9.13 Power Source Condition File Initial Value
9-101
149235-1CD
RE-CSO-A031
POWER SOURCE NO.: 9
POWER SOURCE NAME:
MOTOWELD-S350-AJ2/3
COMMENT: STC NO-CONTROL
POWER SUPPLY: A (synergic)
SHIELDING GAS: CO2
WIRE DIA.: 0.9mm
WIRE STICKOUT: 10mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 0.6sec
POWER SOURCE NO.: 10
POWER SOURCE NAME:
MOTOWELD-S350-AJ2/3
COMMENT: STC NO-CONTROL
POWER SUPPLY: A (synergic)
SHIELDING GAS: MAG
WIRE DIA.: 0.9mm
WIRE STICKOUT: 10mm
WIRE ANTI-STICKING: 0.3sec
ARC FAILURE STOP: 0.6sec
CURRENT VOLTAGE CURRENT VOLTAGE
RANGE: positive
ADJ: 1.00
RANGE: positive
ADJ: 1.00
RANGE: positive
ADJ: 1.00
RANGE: positive
ADJ: 1.00
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(%)
REF.
(V)
MEA.
(A)
REF.
(V)
MEA.
(%)
1.00 60 3.00 85 1.00 55 3.00 85
2.00 80 5.00 95 2.00 80 5.00 95
3.00 100 7.00 100 3.50 110 7.00 100
5.00 125 9.00 105 5.00 130 9.00 105
7.00 150 10.00 110 7.00 170 10.00 110
10.00 190 0.00 0 10.00 190 0.00 0
11.00 200 0.00 0 11.00 200 0.00 0
0.00 0 0.00 0 0.00 0 0.00 0
444 of 493
