CLI Commands
4.16 S
SCALANCE W1750D CLI
278 Function Manual, 03/2019, C79000-G8976-C452-04
Column
Description
New Power
Indicates power values configured on the AP after the ARM change.
Reason
Indicates the reason for changes in channels. For more information about
the reason, see the description below the command output.
show ap arm neighbors
The
show ap arm neighbors command displays the ARM settings on the AP neighbors. The
following example shows the output of the
show ap arm neighbors command:
ARM Neighbors
-------------
bssid essid channel rssi tx-power PL (dB) AP Flags Last Update
----- ----- ------- ---- -------- ------- -------- ------------
6c:f3:7f:45:57:20 7SPOT 1 8 0 0 Passive
6c:f3:7f:56:7e:a0 7SPOT 1 9 0 0 Passive
6c:f3:7f:56:7e:a1 NTT-SPOT 1 12 0 0 Passive
00:24:6c:80:77:c1 NTT-SPOT 1 9 0 0 Passive
6c:f3:7f:45:57:21 NTT-SPOT 1 8 0 0 Passive
6c:f3:7f:44:91:11 NTT-SPOT 1 9 0 0 Passive
00:24:6c:2b:fd:e8 qa-mv-vap3 161 5 9 98 Passive
00:24:6c:80:4d:62 docomo 1 10 0 0 Passive
(Total updates)
---------------
Neighbor Summary:One hop 232 Two hop 0 Current Time: 2013-05-11 04:31:33
The output of this command includes the following information:
Column
Description
bssid
Indicates the BSSID of the AP neighbors.
essid
Indicates the ESSID of the AP neighbors.
Channel
Indicates the channels assigned to the AP neighbors
rssi
Indicates the Received signal strength indication (RSSI) values associated
with the ARM channels to which AP neighbors are connected.
tx power
Indicates the transmission power.
PL
Indicates power loss.
AP Flags
Indicates the status of AP neighbors.
Last Update
Displays details of last updates if any.
Total updates
Displays a summary if updates.
show ap arm rf-summary
The
show ap arm rf-summary command shows the statistics for all channels monitored by an
AP. The following example shows the output of the
show ap arm rf-summary command:
Channel Summary
