CLI Commands
4.16 S
SCALANCE W1750D CLI
282 Function Manual, 03/2019, C79000-G8976-C452-04
11 45787400 1340 0 0 DVACPT 172159
12 132550 1205 0 0 DAC 172051
13 51260 466 0 0 DC 171890
Channel Flags: D: All-Reg-Domain Channel, C: Reg-Domain Channel, A: Activity Present
L: Scan 40MHz Lower, U: Scan 40MHz Upper, Z: Rare Channel
V: Valid, T: Valid 20MHZ Channel, F: Valid 40MHz Channel, P: Valid 40MHZ Channel Pair
O: DOS Channel, K: DOS 40MHz Upper, H: DOS 40MHz Lower
R: Radar detected in last 30 min, X: DFS required
WIF Scanning State
-------------------
Scan mode channel current-scan-channel last-dos-channel timer-milli-tick
--------- ------- -------------------- ---------------- ---------------- Default 161-
48- 0 172161700
Default 1 11- 0 172161700
next-scan-milli-tick (jitter) scans (Tot:Rej:Eff(%):Last intvl(%))
-------------------- ------------------------------------
172172520(4420) 17627:0:100:100
172164890(-4108) 17697:0:100:100
The output of this command includes the following information:
Column
Description
channel
Displays the list of channels configured on the AP.
assign-time(ms)
Displays the time since AP is assigned a channel.
scans-attempted
Indicates the number times an AP has attempted to scan another
channel.
scans-rejected
Displays the number of times an AP was unable to scan a channel,
because the scan was halted due to other ARM settings.
dos-scans
Indicates the number of times services to a rogue device on a chan-
nel were denied by an AP.
flags
Indicates channel flags. For more information on channel flags, see
the flag description below the channel scan time table.
timer-tick
Indicates the time interval since the last scan.
Scan mode
Indicates if the scan mode enabled on the Wi-Fi interface.
channel
(under WIFI Scanning
State)
Indicates the channels available on the Wi-Fi interface.
current-scan-channel
Indicates the current channel scanned.
last-dos-channel
Indicates the last channel on which Denial of Service (DOS) was
detected.
