CLI Commands
4.16 S
SCALANCE W1750D CLI
524 Function Manual, 03/2019, C79000-G8976-C452-04
Mcasts ARP Proxy Pkts Tx Jumbo MTU Rx HB Tx HB MTU Reqs MTU Resps HB Mismatch IP
Mismatch Type
Vlan Translations
------------- --------------- ------- ------- --------- ---------- ---------- -------
-- ------
--- -------------- -------- --- ----- ----- -------- --------- ----------- ----------
- ---- --
---------------
The output of this command provides the following information:
Parameter
Description
L3 Mobility Datapath
Home Table
Displays details such as client index, client MAC address, VLAN, destina-
tion device associated with the L3 mobility home subnet.
L3 Mobility Datapath
Foreign Table
Displays details such as client index, client MAC address, VLAN, Destina-
tion device, home AP IP address, Virtual Controller IP address and packet
details associated with the L3 mobility foreign subnet.
L3 Mobility Datapath
Tunnel table
Displays the following details about L3 mobility tunnel:
• Tunnel - Indicates the tunnel interface.
• Device - Displays the device ID.
• Remote Protocol - Indicates the remote protocol used by the roaming
clients.
• Dest IP - Indicates the destination IP address to which the packets are
routed.
• Clients - Displays the list of clients
• Idle Time - Displays the idle time
• Rx Packets - Displays information about packets received.
• Tx Packets - Displays information about packets transmitted.
• Rx Mcasts - Displays information about multicast packets received.
• Tx Mcasts - Displays information about multicast packets transmitted.
• ARP Proxy Pkts - Displays information packets resolved to destination
IP address by the proxy Address Resolution Protocol (ARP)
• Tx Jumbo MTU - Displays information about the Maximum Transmis-
sion Unit (MTU) in jumbo frames.
• Rx HB
• Tx HB
• MTU Reqs - Indicates the number of MTU requests sent.
• MTU Resps - Indicates the number of MTU responses received.
• HB Mismatch
• IP Mismatch - Indicates IP address mismatch if any
• Type
• Vlan Translations - Displays details about VLAN translation
show l3-mobility events
The following example shows the output of the
show l3-mobility events command:
