CLI Commands
4.16 S
SCALANCE W1750D CLI
Function Manual, 03/2019, C79000-G8976-C452-04
523
--------------------- ---- ------ --------------- ----------------
192.0.1.0 C - - - Controller IP
---------------------
192.0.1.0
Subnet Table
------------
Subnet Netmask VLAN Virtual Controller
------ ------- ---- ------------------
192.0.2.0 255.255.255.255 2 192.0.1.0
The output of this command provides the following information:
Column
Description
Flags
Indicates if any L3 mobility features are enabled.
Type
Indicates the type of the flag.
Value
Indicates if a flag is enabled.
Virtual Controller IP
Displays the Virtual Controller IP address. The Virtual Controller IP con-
figuration for each AP allows the clients to roam seamlessly among all
the APs.
Subnet
Indicates the IP address for the mobility domain.
Netmask
Displays the subnet mask configuration details.
VLAN
Displays the VLAN ID configured for the mobility domain.
Virtual Controller
Displays the Virtual Controller configuration associated with the mobility
domain.
show l3-mobility datapath
The following example shows the output of
show l3-mobility datapath command:
L3 Mobility Datapath Home Table
-------------------------------
Client Index Client MAC Home Vlan Destinaton Device Index
------------ ---------- --------- -----------------------
L3 Mobility Datapath Foreign Table
----------------------------------
Client Index Client MAC Home Vlan VAP Vlan Destinaton Device Index HAP IP Virtual
Controller
IP Packets Forwarded
-------------- -----------------
L3 Mobility Datapath Tunnel Table
---------------------------------
Tunnel Device Remote Protocol Dest IP Clients Idle Time Rx Packets Tx Packets Rx
Mcasts Tx
