YASKAWA NX100 User Manual

7 External Memory Devices
7.3 Operation Flow
7-13
149235-1CD
RE-CSO-A031
Initial Folder Setting
The folder that is contained in a deep hierarchy can be selected in a shortened operation.
When selecting {LOAD}, {SAVE}, {VERIFY}, or {DELETE} from the sub menu of {FD/PC CARD}, the
folder that has been set as an initial folder becomes a current folder.
Operation Explanation
1 Change the security to
management mode.
Select {FD/PC CARD} under
the main menu.
2 Select {FOLDER}. The FOLDER LIST window appears.
3 Move the cursor to a folder
and press [SELECT].
Select a folder that is to be set as a root folder.
4 Select {DISPLAY} --> {ROOT
FOLDER} under the pull-down
menu.
The INITIAL FOLDER SETTING window appears.
A folder currently selected appears in “CURRENT FOLDER” and
the initial folder appears in “ROOT FOLDER.”
[ . . ]
FOLDER LIST
TARGET FOLDER FOLDER 1
FOLDER NUM.
0003
FOLDER 2 FOLDER 3
DATA UTILITY
EDIT
DISPLAY
Main Menu ShortCut
ROOT FOLDER
ROOT ENTRY
AUTO CHANGE OFF
CURRENT FOLDER
C:/FOLDER 1 /FOLDER 2
ROOT FOLDER
C:/
DATA
UTILITY
EDIT
DISPLAY
Main Menu ShortCut
257 of 493
