144
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
6.1 Basic information
In its basic configuration, the server is equipped with one PSU. Besides the
PSU, a second PSU can be installed optionally to serve as a redundant power
supply. If one PSU fails, the second PSU in the redundant configuration ensures
operation, can continue uninterrupted and the defective PSU can be replaced
during operation (hot-plug).
Figure 62: PSU bays
I
The connectors for the PSUs are integrated on the system board,
therefore, the PSUs are connected directly to the system board.
