TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 251
Hard disk drive (HDD) / solid state drive (SSD)
7.4.5.8 Concluding steps
Ê
"Installing the system fan holder" on page 94
Ê "Installing the system air duct" on page 92
Ê "Reassembling" on page 74
Ê "Connecting the power cord" on page 87
Ê "Resuming BitLocker functionality" on page 136
Ê "Switching on the server" on page 90
7.4.6 Removing the 4x 3.5-inch HDD extension box
7.4.6.1 Preliminary steps
Ê
"Suspending BitLocker functionality" on page 111
Ê "Shutting down the server" on page 58
Ê "Disconnecting the power cord" on page 59
Ê Remove all HDD modules from the HDD extension box as described in
section "Removing 3.5-inch HDD modules" on page 220.
Ê "Getting access to the component" on page 61
Ê "Removing the system air duct" on page 91
Ê "Removing the system fan holder" on page 93
7.4.6.2 Removing the 4x 3.5-inch HDD extension box
Ê
Remove all cables from the 4x 3.5-inch HDD extension box backplane.
Ê If applicable, remove all cables from the slimline ODD.
Ê Disengage the accessible drive locking bar as described in section "Opening
the accessible drive locking bar" on page 100.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
tool-less
