TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
479
System board and components
14.6.2 Removing the iRMC microSD card
14.6.2.1 Preliminary steps
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
If applicable, remove the riser module 2 as described in section "Removing
a riser module" on page 98.
14.6.2.2 Removing the iRMC microSD card
Figure 360: Removing the iRMC microSD card
Ê
To eject the iRMC microSD card, gently push it in and then let go (1).
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
a pair of side-cutting pliers
