480
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
System board and components
Ê
Pull the iRMC microSD card straight out of its slot (2).
V CAUTION!
The iRMC microSD card contains customer information. After removing
the iRMC microSD card, hand the card over to the customer.
14.6.2.3 Concluding steps
Ê
If applicable, install the riser module 2 as described in section "Installing a
riser module" on page 95.
Ê
"Reassembling" on page 74
Ê
"Connecting the power cord" on page 87
Ê
"Switching on the server" on page 90
14.6.3 Replacing the iRMC microSD card
14.6.3.1 Preliminary steps
Ê
"Locating the defective server" on page 55.
Ê
"Shutting down the server" on page 58.
Ê
"Disconnecting the power cord" on page 59.
Ê
"Getting access to the component" on page 61
Ê
If applicable, remove the riser module 2 as described in section "Removing
a riser module" on page 98.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
a pair of side-cutting pliers
