Fujitsu PRIMERGY TX2560 M2

464 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
System board and components
14.4.1.2 Installing the TPM
Figure 347: TPM installation kit
Figure 348: Position on the system board
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
0
1
2
