156
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Hard disk drive (HDD) / solid state drive (SSD)
7.2.2 Backplane overviews
Figure 70: Example three backplanes
I
This numbering is based on "Configuration with up to 24 HDD/SSD
modules (three backplanes)" on page 162.
1 SAS backplane 1 in HDD cage 1 (basic configuration)
2 SAS backplane 2 in optional HDD cage 2
3 SAS backplane 3 in optional 8x 2.5-inch HDD extension box
