TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
327
Expansion cards and backup units
Ê
If you want to remove the FBU adapter cable:
Ê
Remove the SAS RAID controller as described in section "Removing
expansion cards from standard slots" on page 300.
Ê
Disconnect the FBU adapter cable from the TFM.
Ê
Install the SAS RAID controller as described in section "Installing
expansion cards in standard slots" on page 295.
9.4.3.3 Concluding steps
Ê
"Reassembling" on page 74
Ê
"Connecting the power cord" on page 87
9.4.4 Replacing an FBU
V CAUTION!
Do not throw battery backup units into the trash can. Batteries must be
disposed of in accordance with local regulations concerning special
waste.
For further safety information, please refer to section "Environmental
protection" on page 52.
9.4.4.1 Preliminary steps
Ê
"Disabling SVOM boot watchdog functionality" on page 112
Ê
"Locating the defective server" on page 55
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
"Locating the defective component" on page 57
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
tool-less
