TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
313
Expansion cards and backup units
Figure 220: Removing an expansion card from a riser module
Ê
Carefully remove the expansion card from its slot.
9.3.6.3 Installing the slot cover
Figure 221: Installing the PCI slot cover
Ê
Insert the slot cover.
Ê
Install the slot cover lock as described in section "Installing the slot cover
lock" on page 311.
9.3.6.4 Concluding steps
Ê
"Reassembling" on page 74
Ê
"Connecting the power cord" on page 87
Ê
"Resuming BitLocker functionality" on page 136
