TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 91
Basic hardware procedures
4.8 Handling the system air duct
4.8.1 Removing the system air duct
Figure 41: Removing the system air duct
Ê Press in on the locking tab (1) while slightly lifting up the system air duct.
Ê Remove the system air duct from of the chassis (2). Use the green touch
points (A) to hold the system air duct.
A
A
