Fujitsu PRIMERGY TX2560 M2

554 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Appendix
17.2.2 Server front
17.2.2.1 Indicators on the front panel
Figure 424: Indicators on the front panel module
Pos. Label Indicator Status Description
1 ID
ID indicator,
see also
"iRMC-related
status signals"
on page 556
blue on
The server has been highlighted
using ServerView Operations
Manager, iRMC web frontend or the
ID button on the front panel for easy
identification
blue
flashing
The server has been highlighted for
easy identification using the iRMC
(AVR) with disabled local VGA
output.
2 [CSS] CSS indicator
off
No critical event detected (CSS
component).
orange
on
Prefailure event detected (CSS
component).
For HDDs see also "HDD prefailure
detection" on page 557
orange
flashing
CSS component failure detected.
