190
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Hard disk drive (HDD) / solid state drive (SSD)
7.2.13.7 Concluding steps
Ê
"Installing the system fan holder" on page 94
Ê
"Installing the system air duct" on page 92
Ê
Install all removed HDD/SSD modules as described in sections "Installing a
2.5-inch HDD/SSD module" on page 174.
Ê
"Reassembling" on page 74
Ê
"Connecting the power cord" on page 87
Ê
"Switching on the server" on page 90
7.2.14 Replacing SAS backplanes (configuration with up
to 32 HDD/SSD modules)
7.2.14.1 Preliminary steps
Ê
"Locating the defective server" on page 55
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
Remove all HDD/SSD modules as described in section "Removing 2.5-inch
HDD/SSD modules" on page 175.
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools:
Phillips PH2 / (+) No. 2 screw driver
