Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Hard disk drive (HDD) / solid state drive (SSD)
7.4.2 Installing the 8x 2.5-inch HDD extension box
7.4.2.1 Preliminary steps
Ê
"Suspending BitLocker functionality" on page 111
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
7.4.2.2 Removing accessible drive dummy covers
Ê
Remove accessible drive filler covers from the required bays as described
in section "Accessible drive filler covers" on page 104.
Ê
Remove accessible drive covers as described in section "Accessible drive
covers" on page 106.
7.4.2.3 Installing the HDD/SSD backplane
Ê
If applicable, install the HDD/SSD backplane on the 8x 2.5-inch HDD
extension box as described in section "Installing the new HDD/SSD
backplane" on page 246.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
Slotted screw driver (for bending in or out accessible drive mounting
brackets)
