Fujitsu PRIMERGY TX2560 M2

TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 159
Hard disk drive (HDD) / solid state drive (SSD)
7.2.3 Configuration with up to eight HDD/SSD modules
(one backplane)
Mounting order
Figure 73: Mounting order for up to 8x 2.5-inch HDDs/SSDs
HDD/SSD naming scheme
Figure 74: Naming scheme for up to 8x 2.5-inch HDDs/SSDs
