TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
253
Hard disk drive (HDD) / solid state drive (SSD)
7.4.6.4 Concluding steps
Ê
"Installing the system fan holder" on page 94
Ê
"Installing the system air duct" on page 92
Ê
"Reassembling" on page 74
Ê
"Connecting the power cord" on page 87
Ê
"Resuming BitLocker functionality" on page 136
Ê
"Switching on the server" on page 90
7.4.7 Replacing the HDD backplane on the 4x 3.5-inch
HDD extension box
7.4.7.1 Preliminary steps
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
Remove all HDD modules from the HDD extension box as described in
section "Removing 3.5-inch HDD modules" on page 220.
Ê
"Getting access to the component" on page 61
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
7.4.7.2 Removing the defective HDD backplane
Ê
Unlock and pull the 4x 3.5-inch HDD extension box out of its installation bays
as described in section "Removing the 4x 3.5-inch HDD extension box" on
page 251.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
Phillips PH2 / (+) No. 2 screw driver
