Fujitsu PRIMERGY TX2560 M2 Upgrade And Maintenance Manual

TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 237
Hard disk drive (HDD) / solid state drive (SSD)
7.4 HDD extension boxes
7.4.1 HDD extension boxes overview
7.4.1.1 8x 2.5-inch HDD extension box
Figure 151: 8x 2.5-inch HDD extension box
I The 8x 2.5-inch HDD extension box occupies accessible drive bays 2
and 3 (see figure 286 on page 393).
7.4.1.2 4x 3.5-inch HDD extension box
Figure 152: 4x 3.5-inch HDD extension box
I The 4x 3.5-inch HDD extension box occupies accessible drive bays 1, 2
and 3 (see figure 286 on page 393).

Fujitsu PRIMERGY TX2560 M2 Specifications

General

Brand	Fujitsu
Model	PRIMERGY TX2560 M2
Category	Server
Language	English
