TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
231
Hard disk drive (HDD) / solid state drive (SSD)
7.3.13 Upgrading to 8x 3.5-inch HDD configurations
7.3.13.1 Preliminary steps
Ê
"Suspending BitLocker functionality" on page 111
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
Remove all HDD modules as described in section "Removing 3.5-inch HDD
modules" on page 220.
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
7.3.13.2 Removing the 3.5-inch HDD bay top cover
Ê
Remove the 3.5-inch HDD bay top cover as described in section "Removing
the 3.5-inch HDD bay top cover" on page 224).
Upgrade and Repair Unit
(URU)
Hardware: 20 minutes
Tools:
Phillips PH2 / (+) No. 2 screw driver
