TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
265
Hard disk drive (HDD) / solid state drive (SSD)
7.6 Non-hot-plug 2.5-inch HDD/SSD
7.6.1 Replacing a non-hot-plug HDD/SSD
7.6.1.1 Preliminary steps
Ê
"Suspending BitLocker functionality" on page 111
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
I
Locate the defective HDD/SSD as described in section "Configuration
with non-hot-plug HDDs/SSDs" on page 216.
7.6.1.2 Removing the non-hot-plug cage
Ê
Disconnect the cable from the non-hot-plug HDD/SSD 1.
Ê
If applicable, disconnect the cable from the non-hot-plug HDD/SSD 2.
Customer Replaceable Unit
(CRU)
Hardware: 10 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver
– Phillips PH0 / (+) No. 0 screw driver
