Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Expansion cards and backup units
9.3.8 Replacing a riser card
9.3.8.1 Preliminary steps
Ê
"Suspending BitLocker functionality" on page 111
Ê
"Disabling SVOM boot watchdog functionality" on page 112
Ê
"Locating the defective server" on page 55
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
"Locating the defective component" on page 57
Ê
Remove the corresponding riser module as described in section "Removing
a riser module" on page 98.
Ê
Remove all expansion cards installed in the riser module as described in
section "Removing expansion cards from riser modules" on page 312.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools:
Phillips PH2 / (+) No. 2 screw driver
