TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
395
12.2 Installing accessible drives
12.2.1 Preliminary steps
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
I
The front cover only needs to be removed in order to remove
accessible drive dummy covers.
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
Ê
If applicable, "Removing a riser module" on page 98
Ê
If applicable, remove an expansion card in slot 1 as described in section
"Removing expansion cards from standard slots" on page 300.
12.2.2 Removing accessible drive dummy covers
Ê
Remove accessible drive filler covers from the required bays as described
in section "Accessible drive filler covers" on page 104.
Ê
Remove accessible drive covers as described in section "Accessible drive
covers" on page 106.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
Slotted screw driver (for bending in or out accessible drive mounting
brackets)
