360 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Main memory
10.2.2 Installing a memory module
Ê Identify the correct memory slot according to the mounting order described
in section "Basic information" on page 350.
Figure 256: Installing memory modules (A)
Ê Press out the securing clip at each end of the memory slot.
Figure 257: Installing memory modules (B)
Ê Align the notch on the bottom of the module with the crossbar in the slot.
Ê Press down on the memory module until the securing clips snap into the cut-
outs at each end of the module.
10.2.3 Concluding steps
Ê "Installing the system air duct" on page 92
Ê "Reassembling" on page 74
Ê "Connecting the power cord" on page 87
Ê If applicable, "Updating or recovering the system board BIOS and iRMC" on
page 119
Ê "Enabling SVOM boot watchdog functionality" on page 130
Ê If applicable, "Verifying the memory mode" on page 132
Ê "Resuming BitLocker functionality" on page 136
