Hard disk drive (HDD) / solid state drive (SSD)
7.3.3 Configuration with up to four HDD modules
(one backplane)
Mounting order
Figure 120: Mounting order for up to 4x 3.5-inch HDDs
HDD naming scheme
Figure 121: Naming scheme for up to 4x 3.5-inch HDDs
