566
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
17.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
Take the system down to its minimum startup configuration.
Ê
"Connecting the power cord" on page 87
Ê
Connect a keyboard, mouse and display to the server.
Ê
Switch on the server as described in section "Switching on the server" on
page 90.
Field Replaceable Units (FRU)
Components Notes
System board
no TPM, UFM, expansion cards or
DynamicLoM module installed
1 CPU with CPU heat sink installed in CPU slot CPU 1
1 memory module installed in DIMM slot 1A
Front panel module without connected USB3.0 and front VGA
1 PSU installed in PSU bay PSU 1
Table 9: Minimum startup configuration - components
Cables Notes
Front panel cable connected to system board
Power cable
Table 10: Minimum startup configuration - cables
