12.7.3 Replacing the ultraslim ODD
12.7.3.1 Preliminary steps
Ê
"Locating the defective server" on page 55
Ê
"Removing backup and optical disk media" on page 114
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
I
Removing the front cover is not required in order to replace the
ultraslim ODD.
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
12.7.3.2 Removing the defective ultraslim ODD
Ê
Remove the ultraslim ODD adapter as described in section "Removing an
accessible drive" on page 402.
Ê
Remove the ultraslim ODD as described in section "Removing the ultraslim
ODD from the ultraslim ODD adapter" on page 430.
12.7.3.3 Installing the new ultraslim ODD
Ê
Install the ultraslim ODD as described in section "Installing the ultraslim
ODD into the ultraslim ODD adapter" on page 428.
Ê
Install the ultraslim ODD adapter as described in section "Installing an
accessible drive" on page 398.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
– Phillips PH0 / (+) No. 0 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
