Fujitsu PRIMERGY TX2560 M2

TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 559
Appendix
17.2.3 Server rear
17.2.3.1 Connectors on the I/O panel
Figure 427: Connector panel
1 Video connector (blue) 4 DynamicLoM (optional, different
variants)
2 COM1 connector (optional)* 5 2 USB connectors (USB 3.0)
3 Management LAN connector 6 2 USB connectors (USB 2.0)
** The serial interface COM1 can be used as the standard interface or for communication
with iRMC.
