TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
319
Expansion cards and backup units
9.4.2 Installing an FBU
V CAUTION!
For further safety information, please refer to chapter "Important
information" on page 43.
9.4.2.1 Preliminary steps
Ê
"Disabling SVOM boot watchdog functionality" on page 112
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
Disconnect the SAS cables from the SAS RAID controller.
Ê
Remove the SAS RAID controller from its slot as described in section
"Removing expansion cards from standard slots" on page 300.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
Phillips PH1/(+) No. 1 screw driver
