446
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Front panel and external connectors
13.2.2 Removing the front VGA connector
13.2.2.1 Preliminary steps
Ê
"Suspending BitLocker functionality" on page 111
Ê
"Locating the defective server" on page 55
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
Ê
"Removing the front panel module" on page 437
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
– Phillips PH0 / (+) No. 0 screw driver
– Side cutter (for cable tie)
