Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Hard disk drive (HDD) / solid state drive (SSD)
7.5.2 Replacing the PCIe SSD backplane on the
8x 2.5-inch PCIe SSD extension box
7.5.2.1 Preliminary steps
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
Remove all 2.5-inch PCIe SSDs SFF from the PCIe SSD extension box as
described in section "Removing 2.5-inch HDD/SSD modules" on page 175.
Ê
"Getting access to the component" on page 61
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
7.5.2.2 Removing the defective PCIe SSD backplane
Ê
Unlock and pull the 8x 2.5-inch PCIe SSD extension box out of its installation
bays as described in section "Removing the 8x 2.5-inch HDD extension box"
on page 242.
I
The PCIe SSD extension box has the same cage as the 8x 2.5-inch
HDD extension box but instead of the two HDD backplanes, there are
two PCIe SSD backplanes.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
Phillips PH2 / (+) No. 2 screw driver
